Schiit Audio Jotunheim R Desktop Direct Drive Amplifier & Preamplifier for RAAL-requisite SR1a

S$1,699.00
Why You Should Get It
  • Direct Drive RAAL-SR1a Amplifier
  • Designed specifically for only the SR1a
  • Direct plug-and-play, SR1a “Amp/Ribbon Interface” box will not be required
  • Optional internal DAC upgrade option available
Demo unit available for audition at our office (12pm-8pm on weekdays). Click here to view how to get to us easily.
Warranty
5 years (local)

Do you have Raal/Requisite headphones? Do you want to ditch the speaker amp and interface box for something smaller and simpler? Do you want a true one-box solution you can carry with you wherever you go? Then you want Jotunheim R—the only direct-drive ribbon headphone amp on the planet.

Designed Especially for Raal/Requisite Headphones
Let’s be clear. If you have other kinds of headphones, this amp isn’t for you. This amp was designed for one kind of headphones only: the Raal/Requisite ribbon headphones. Delivering up to 13A (amps…yes, amps) per channel into the Raal’s extremely low impedance load, and including the baffle compensation needed for the SR1a, the Jotunheim R is completely unique. It means you can leave your speaker amp behind, forget the Raal/Requisite interface box, and, if you buy it with the optional True Multibit™ DAC, you have a one-box system that’s easily transportable.

Configure To Your Needs
Select Jotunheim R as “just an amp,” or add an internal or external DAC to tailor the system to your needs.
  • No DAC. If you already have a DAC, or don’t need one, choose Jotunheim R without a DAC module or external DAC, for $799.
  • True Multibit DAC module (internal). Choose the optional Multibit DAC Module to get Schiit’s unique digital filter and multibit DAC architecture, for $200 more.
  • Bifrost 2 DAC (external). Or choose the all-new, modular Bifrost 2 DAC for even higher performance, for $600 more.
Flexibility and Convenience
Jotunheim R provides switchable baffle compensation, to ensure compatibility with future ribbon headphone models, as well as switchable passive preamp outputs, and both balanced and single-ended inputs. No power bricks or external power supplies are required; it plugs straight into the wall for maximum convenience.

Unique Nexus™ Discrete Gain Stage with Ultra-High-Current Output
Jotunheim uses our unique Nexus™ gain stage that debuted on the flagship Ragnarok 2 integrated amplifier. This inherently balanced, differential, current feedback topology accepts both balanced and single-ended input without the need for splitters and summers.

Designed and Built in California
By “designed and built in California" this is what we mean: the vast majority of the total production cost of Jotunheim—chassis, boards, transformers, assembly, etc—goes to US companies manufacturing in the US. Our chassis are made minutes from our facility. Our PCBs are done just over the hill from us, or done in NorCal. Our transformers are also made in California. You get the picture.

5-Year Warranty and Easy Return Policy
Jotunheim R is covered by a 5-year limited warranty that covers parts and labor.
Product Availability Available
Product Type Amplifier (Power)
Style/Type Desktop
DAC Analog Devices AD5547
Sampling / Bitrate up to 24bits/192kHz
Frequency Response (Hz) 20Hz-20Khz, +/-0.1db, 2Hz-500KHz, -3dB, baffle compensation off into SR1a load
Impedance (Ω) Output: Less than 0.015 ohms; Input: 50K ohms
Signal-to-Noise Ratio (SNR) >110dB, referenced to 3A output
Total Harmonic Distortion (THD) <0.0005% at 32 ohms, 1V (not a ribbon headphone load, for reference, note max output at 1% THD into 8-32 ohms is about 5V RMS)
Microphone None
Input Connectivity Options Coaxial, XLR (3-Pin)
Output Connectivity Options XLR (Dual 3-Pin) [Balanced]
Colour Black
Product Weight (g) 3175
Warranty 5 years (local)
Additional Tech Specs

Amplifier



  • Maximum Current, SR1a load: 13.2A per channel, both channels driven, at clipping (10% THD)
  • THD: <0.0005% at 32 ohms, 1V (not a ribbon headphone load, for reference, note max output at 1% THD into 8-32 ohms is about 5V RMS)
  • THD at 0.2A output into SR1a: <0.014%
  • THD at 1A output into SR1a: <0.026%
  • IMD: <0.02% at 0.2A output current, <0.04% at 1A output current into SR1a
  • Crosstalk: >-65dB, 20 Hz-20KHz, when loaded with SR1a
  • Output Impedance: Less than 0.015 ohms
  • Input Impedance: 50K ohms
  • Gain: 2 (6dB)
  • Inputs: Balanced XLR and Single-Ended RCA, selectable via front switch
  • Outputs: Balanced Raal headphone (4-pin male XLR), balanced passive preamp, single-ended passive preamp
  • Optional Inputs: True Multibit™ DAC
  • Gain Stage: Proprietary Schiit Nexus™ fully discrete differential current-feedback topology
  • Power Supply: One 48VA transformer with 6 stages of discrete or integrated regulation and over 120,000uF total filter capacitance
  • Protection: Hall Effect current sensor for overcurrent conditions, triggering at 31A, plus integrated thermostat triggering at 95 degrees C



Optional Multibit DAC:

  • USB Input Receiver: C-Media CM6631A
  • D/A Conversion IC: Analog Devices AD5547
  • Digital Filter: Schiit Time- and Frequency-domain Optimized DSP filter
  • Analog Output: fully differential, active summing and filtering
  • Frequency Response: 20Hz-20KHz, +/-0.25dB, 2-100kHz, -3dB
  • THD: <0.005%, 20Hz-20KHz, full scale
  • IMD: <0.006%, CCIR
  • S/N: >109dB, referenced to 2V RMS, unweighted



  • Power Consumption: 45W maximum
  • Size: 9” x 6” x 2”
  • Weight: 7 lbs
