NAD

NAD D 3020 V2 Hybrid Digital DAC & Hi-Fi Integrated Amplifier (with Phono Built-In)

S$699.00
Why You Should Get It
  • 2 x 30W
  • AptX Bluetooth music streaming
  • MM Phono input for Vinyl
  • Preamp Output for added connectivity (Full Range)
  • Optical and Coaxial Digital inputs
  • Line Inputs • Subwoofer Output
  • Bass EQ setting
Warranty
1 year (local)

Reinventing an Icon

By adapting to today’s media sources and using state-of-the-art digital technology for the new world of digital music, the D 3020 puts a completely modern spin on a revered icon. The original designer of the 3020, NAD’s Director of Advanced Technology, Bjorn Erik Edvardsen, has been pivotal in developing the D 3020 for the new digital generation. Offering an excellent quality 24/192 DAC with 8 channels mixed to 2 for improved resolution, the D 3020 V2 represents the same kind of value-bending innovation that gave the original 3020 its legendary overachieving phono stage.

More Connected

The D 3020 offers inputs for your digital and analogue sources. Coaxial and optical inputs allow many different digital sources to be connected, from CD and DVD players, to set top boxes, media streamers like AppleTV, or satellite and cable receivers. There are also analogue inputs including a sophisticated MM Phono input. Far from just another set of sockets, this Phono stage includes highly accurate RIAA equalization, an Infrasonic Warp Filter, and features both high overload margins and extremely low noise. With V2 we’ve also added a PreOut for increased connectivity in the output stage.

Power that Delivers

Power output may sound small at 30W per channel, but like all NAD amplifiers this is very misleading, as a properly designed 30W amplifier can sound superior to a 100W amplifier from a lesser brand. With its very small form factor, the D 3020 will astound many for its ability to drive difficult loudspeakers to satisfying levels without adding noise or distortion.

Real World Performance

NAD rewrote the rules for amplifiers when designing the original 3020. Instead of letting laboratory test equipment have the last word, we made sure that we could properly drive real loudspeakers with real music for the real world. The D 3020 lives up to this promise through a unique implementation of NAD PowerDrive™ developed by Edvardsen, that allows low impedance drive (current) and high dynamic power (voltage) at vanishingly low distortion levels. This refinement of PowerDrive combined with a precision soft clipping circuit, lets the D 3020 sound even more powerful than it already is. An innovative Bass EQ circuit helps small speakers sound big without overdriving or damaging ported woofers.

Stream with Bluetooth

The D 3020 V2 delivers the convenience of wireless streaming with its Bluetooth® capability. Stream all your music from a smartphone, tablet, or laptop. The D 3020 even supports the highest audio quality Bluetooth, aptX®, which is becoming ever more popular for its excellent sound quality and low power consumption compared to Wi-Fi.

Mean and Green

The D 3020’s highly efficient design wastes less energy, requiring only 20% of the power needed by traditional Hi-Fi amplifiers. It’s like trading in a gas guzzling car for a hybrid vehicle. Standby power consumption is a miniscule <0.5W. NAD has taken amplification to new lows, with lower distortion, lower noise, and lower power consumption. NAD’s major focus is to find new technology that improves musical performance while consuming less power and using fewer non-renewable resources in manufacturing.

Product Availability Available
Product Type Amplifier (Headphone), Amplifier (Integrated), Amplifier (Preamplifier)
Style/Type Desktop
Features aptX, aptX HD, Bluetooth, Line-in, Line-out, Optical Input, SBC
Sampling / Bitrate up to 24bit/192kHz (via Digital Audio input)
Frequency Response (Hz) 20 Hz – 20 kHz (±0.3 dB)
Impedance (Ω) 1.15 mV (ref. 500 mV out, Volume maximum)
Signal-to-Noise Ratio (SNR) ≥90dB
Total Harmonic Distortion (THD) ≤0.005%
Amp Output Power (mW / W) Rated Power at 8 ohms: 2 x 30 Watts; IHF Dynamic Power 8 ohms: 2 x 60 Watts; 4 ohms: 2 x 100 Watts; 2 ohms: 2 x 150 Watts
Microphone None
Input Connectivity Options 3.5mm stereo, Binding Posts (Banana Plug Sockets), Bluetooth, Coaxial, Optical, RCA (Phono signal) [Phono Pre-amp built-in]
Output Connectivity Options 3.5mm Stereo, Binding Posts (Banana Plug Sockets)
Colour Black
Warranty 1 year (local)
Additional Tech Specs

Refer to official NAD website for full Technical Specifications

If you're based in Singapore

  • spend $300 or more for free doorstep courier delivery.
  • add a few more bucks, for even quicker prioritised delivery.
  • self-collection is possible at our Showroom, based in Tai Seng. Find out where, and how to get to us here.
  • and yes, you may arrange your own 3rd party logistics to pickup your purchases on your behalf.
    Grab, Lalamove, GoGoX services are welcome.






Friends from Overseas,

  • we do ship internationally.
  • shipping fees will be displayed during checkout.
  • do be aware of import tax/VAT that may apply.



No Reviews Available Yet. Leave Your Review

Reinventing an Icon

By adapting to today’s media sources and using state-of-the-art digital technology for the new world of digital music, the D 3020 puts a completely modern spin on a revered icon. The original designer of the 3020, NAD’s Director of Advanced Technology, Bjorn Erik Edvardsen, has been pivotal in developing the D 3020 for the new digital generation. Offering an excellent quality 24/192 DAC with 8 channels mixed to 2 for improved resolution, the D 3020 V2 represents the same kind of value-bending innovation that gave the original 3020 its legendary overachieving phono stage.

More Connected

The D 3020 offers inputs for your digital and analogue sources. Coaxial and optical inputs allow many different digital sources to be connected, from CD and DVD players, to set top boxes, media streamers like AppleTV, or satellite and cable receivers. There are also analogue inputs including a sophisticated MM Phono input. Far from just another set of sockets, this Phono stage includes highly accurate RIAA equalization, an Infrasonic Warp Filter, and features both high overload margins and extremely low noise. With V2 we’ve also added a PreOut for increased connectivity in the output stage.

Power that Delivers

Power output may sound small at 30W per channel, but like all NAD amplifiers this is very misleading, as a properly designed 30W amplifier can sound superior to a 100W amplifier from a lesser brand. With its very small form factor, the D 3020 will astound many for its ability to drive difficult loudspeakers to satisfying levels without adding noise or distortion.

Real World Performance

NAD rewrote the rules for amplifiers when designing the original 3020. Instead of letting laboratory test equipment have the last word, we made sure that we could properly drive real loudspeakers with real music for the real world. The D 3020 lives up to this promise through a unique implementation of NAD PowerDrive™ developed by Edvardsen, that allows low impedance drive (current) and high dynamic power (voltage) at vanishingly low distortion levels. This refinement of PowerDrive combined with a precision soft clipping circuit, lets the D 3020 sound even more powerful than it already is. An innovative Bass EQ circuit helps small speakers sound big without overdriving or damaging ported woofers.

Stream with Bluetooth

The D 3020 V2 delivers the convenience of wireless streaming with its Bluetooth® capability. Stream all your music from a smartphone, tablet, or laptop. The D 3020 even supports the highest audio quality Bluetooth, aptX®, which is becoming ever more popular for its excellent sound quality and low power consumption compared to Wi-Fi.

Mean and Green

The D 3020’s highly efficient design wastes less energy, requiring only 20% of the power needed by traditional Hi-Fi amplifiers. It’s like trading in a gas guzzling car for a hybrid vehicle. Standby power consumption is a miniscule <0.5W. NAD has taken amplification to new lows, with lower distortion, lower noise, and lower power consumption. NAD’s major focus is to find new technology that improves musical performance while consuming less power and using fewer non-renewable resources in manufacturing.

Product Availability Available
Product Type Amplifier (Headphone), Amplifier (Integrated), Amplifier (Preamplifier)
Style/Type Desktop
Features aptX, aptX HD, Bluetooth, Line-in, Line-out, Optical Input, SBC
Sampling / Bitrate up to 24bit/192kHz (via Digital Audio input)
Frequency Response (Hz) 20 Hz – 20 kHz (±0.3 dB)
Impedance (Ω) 1.15 mV (ref. 500 mV out, Volume maximum)
Signal-to-Noise Ratio (SNR) ≥90dB
Total Harmonic Distortion (THD) ≤0.005%
Amp Output Power (mW / W) Rated Power at 8 ohms: 2 x 30 Watts; IHF Dynamic Power 8 ohms: 2 x 60 Watts; 4 ohms: 2 x 100 Watts; 2 ohms: 2 x 150 Watts
Microphone None
Input Connectivity Options 3.5mm stereo, Binding Posts (Banana Plug Sockets), Bluetooth, Coaxial, Optical, RCA (Phono signal) [Phono Pre-amp built-in]
Output Connectivity Options 3.5mm Stereo, Binding Posts (Banana Plug Sockets)
Colour Black
Warranty 1 year (local)
Additional Tech Specs

Refer to official NAD website for full Technical Specifications
